Chapter 4 Installing Mass Storage
31
•
Remove the drive's termination jumper. (The SCSI cable to the
internal drives is terminated.)
For instructions, refer to the disk drive's installation guide.
3. Choose the drive bay that the device will occupy. Remove the filler panel
that covers the bay.
4. Reach into the bay and pull out the data communication cable and a power
cable.
The three drive bays are served by one SCSI data cable with several
connectors, and by several free power cables. Select the SCSI connector
and power cable that are nearest to the drive bay you selected.
5. Hold the drive in front of the drive bay (Figure 4-1). Connect the SCSI
data cable and the power cable to the rear of the drive.
Figure 4-1. Installing a Hard Disk Drive
