Chapter 3 Opening and Closing the
HP NetServer
26
Spring-loaded
hinge pins
Figure 3-8. Top Cover in Open Position
7. When the NetServer is mounted in a rack, adjacent components can block
the cover from opening fully. If this happens, remove the cover entirely:
a. Swing open the cover as far as possible.
b. Pull back one of the spring-loaded hinge pins on the underside of the
cover. See Figure 3-8.
c. Lift the cover off.
d. To replace the cover, pull back one of the spring-loaded hinge pins,
and then position the cover so the hinge pins line up with the
matching holes in the satellite chassis. (See Figure 3-8.) Release the
pin so that it snaps into the hole.
NOTE As a safety measure, and to avoid cooling problems, you must
always replace the cover before turning on the HP NetServer.
