Example 2:
The following shows an example of information acquired by executing sample script KTDEMO13 (the
KTLOAD , KTQRYTPG , and KTQRYRLC commands). This information shows the page relocation status
of each volume in the tiering policy group TPG1 and the tier relocation progress for each Smart Tiers
Z pool.
Tiering Policy Group Name: TPG1
Volumes
POOL
Devn,Volser,SN ,CU,CCA, ID,TLv,RelocateStatus ,LocatedPage/ TotalPage
0000,VOL001,14001,00, 00, 1, 3,done , 1/ 1
:
Pools
Relocate RelocateTime MigrationPage
SN , ID, Type,Monitor,active %,Start, End,ExpectedCt,MigratedCt
14001, 1, DT, auto,Y 100%,00:00,01:00, 0, 0
:
Pools tier status
SN , ID,Tier, Used/ Capacity,EntryBuf%,RelocBuf%,Media
14001, 1, 1, 1/ 26 0%, 2%,"SSD"
14001, 1, 2, 263/ 2631 8%, 2%,"SAS 15K"
14001, 1, 3, 1036/ 131578 8%, 2%,"SATA 7.2K"
14001, 2, 1, 2/ 26 0%, 2%,"SSD"
14001, 2, 2, 263/ 2631 8%, 2%,"SAS 15K"
14001, 2, 3, 1036/ 131578 8%, 2%,"EXTERNAL H"
:
Related topics
• Creating a tiering policy group definition file , page 65
• KTLOAD , page 94
• KTQRYRLC , page 99
• KTQRYTPG , page 101
• KTDEMO12 (Check the page relocation status) , page 191
• KTDEMO13 (Check the relocation progress) , page 194
Checking volume I/O performance
By executing the KTQSTATS command, you can acquire I/O performance information (number of
I/O operations for the drive media) for each volume in a tiering policy group. You can view the
acquired information to check if there is any problem with the I/O performance of volumes.
Prerequisites
• Creating a tiering policy group definition file
To check volume I/O performance:
1. Execute the KTLOAD command.
The contents of the configuration files are loaded into REXX variable structures.
Smart Manager for Mainframe operation 70
