Page 94
Edition 3
Rev G
Section 4
4-9
17. If INPUT TYPE/RANGE selected was not SWITCH CONTACT, press the
to advance to the next
parameter, RANGE LIMIT LOW.
18. If INPUT TYPE/RANGE selected was not SWITCH CONTACT, press the
to advance to the next
parameter, RANGE LIMIT HIGH.
Press the
to change, then
to
desired value, or
then ,
then press
.
Press the
to change, then
to
desired value, or
then ,
then press
.
I
N
P
U
T
S
Units correspond to
units configured in step
13 or 14.
Units correspond to
units configured in step
13 or 14.
IVx RANGE LIMIT LOW
0 units
Selections
±
999999
(decimal position = 0)
±
9.9999
(decimal position = 4)
IVx RANGE LIMIT HIGH
100 units
Selections
±
999999
(decimal position = 0)
±
9.9999
(decimal position = 4)
