Page 91
Section 4
Edition 3
Rev G
4-6
8. If INPUT TYPE/RANGE selected was mA, mV, or VOLT, press the
to advance to the next parameter,
INPUT RANGE HIGH.
9. If INPUT TYPE/RANGE selected was PULSE, press the
to advance to the next parameter, PULSE
RATE HIGH. (Not Yet Available)
10. If INPUT TYPE/RANGE selected was COMMS, press the
to advance to the next parameter,
COMMS ADDRESS.
Press the
to change, then
or
, then
, then
press
.
IVx PULSE RATE HIGH
1000 PULSES / SEC
Selections
30 to 99999
Press the
to change, then
,
to desired value, then press the
.
Press the
to change, then
to
desired address, then press the
.
I
N
P
U
T
S
Units correspond to units
configured in INPUT
TYPE/RANGE, mA, mV
or VOLT.
IVx INPUT RANGE HIGH
100.000 units
Selections
±
999
IVx COMMS ADDRESS
1
Selections
1 to 247
