4. Press the to advance to the next parameter, INPUT TYPE/RANGE.
5. Press the to advance to the next parameter:
OFF-NO INPUT selected, no other prompts for Input x will be seen, go to Step 1, Pg. 4-1.
TC TYPE selected, go to Step 5A.
RTD TYPE selected, go to Step 5B
mV, mA, Volt, Switch Contact go to Step 6.
COMMS, go to Step 6.
5A.
Press the to advance to step 5C.
Press the to change, then ,
to desired choice, then press the
.
I
N
P
U
T
S
Press the to change, then ,
to desired choice, then press the
.
IVx TC TYPE
J
Selections
J,K,E,T,S
R,B,N,C,G
D
NI/NI-MOLY
PLATINEL II
IVx INPUT TYPE / RANGE
OFF - NO INPUT
Selections
OFF-NO INPUT
TC NARROW TC WIDE
RTD mA
25mV 100mV
1 VOLT 10 VOLT
SWITCH CONTACT
COMMS
