Page 133
Section 4
Edition 3
Rev G
4-48
6. Press the
to advance to the next parameter, RECORDING METHOD.
7. Press the
to advance to the next parameter, DECIMAL POSITION.
8. Press the
to advance to the next parameter, CHART DIVISIONS.
R
E
C
O
R
D
E
R
S
Rx RECORDING METHOD
DRAG - MIN TO MAX
Selections
INSTANTANEOUS VALUES
CONNECT THE VALUES
DRAG - MIN TO MAX
AVERAGE VALUES
CONNECT THE AVERAGES
Press the
to change, then
to
desired choice, then press the
.
Rx DECIMAL POSITION
0
Selections
0 to 4
Press the
to change, then
to
desired number, then press the
.
Rx CHART DIVISIONS
(RINGS) 100
Selections
10 to 200
Press the
to change, then
to
desired value, then press the
.
Must be programmed
before any subsequent
prompts
