9. Press the
to advance to the next parameter, OUTPUT 2 PERCENT UPPER LIMIT (only seen if OUT 2
TYPE is PID).
Cx OUT 2 PERCENT
UPPER LIMIT 100%
Selections
1 to100
10.Press the
to advance to the next parameter, OUTPUT 1 PERCENT ON ERROR (only seen if OUT 1
TYPE is PID).
Cx OUT 1 PERCENT
ON ERROR 0%
Selections
1 to100
11.Press the
to advance to the next parameter, OUTPUT 2 PERCENT ON ERROR (only seen if OUT 2
TYPE is PID).
Cx OUT 2 PERCENT
ON ERROR 0%
Selections
1 to100
Press the
to change, then
or
to desired choice, then press the
.
Press the
to change, then
or
to desired choice, then press the
.
Press the
to change, then
or
to desired choice, then press the
.
