46 LUN Manager for the XP128/XP1024
NOTE: High-speed (2 port) mode is available only if the XP disk array has firmware version 21.06.22 or
later installed.
The following icons are used to indicate status:
Port table
The Port table displays information about the ports in the selected CHA packages. The information in this
table differs depending on the type of channel adapter package selected in the tree.
The table lists the following for Fibre Channel CHA packages:
• Port Name: Displays port names
• Type: Fibre indicates a Fibre Channel port, used for connecting open system hosts. MF-Serial indicates
an ESCON ® port, used for connecting mainframe hosts.
• Host Speed: Specifies the data transfer speed for Fibre Channel ports. If Auto is selected, the disk array
automatically sets the data transfer speed to 1 GB/sec or 2 GB/sec.
• Addr (Loop ID): Displays addresses of ports. You can change port addresses.
• Fabric: Specify ON if a fabric switch is used, or OFF if no fabric switch is used
• Connection: Specifies the topology. The default is FC-AL. Some fabric switches require you to specify
point-to-point topology. Check the switch’s documentation.
• Attribute: Indicates whether the port is an initiator port, target port, RCU target port, or external port
• WWN: Displays WWNs of ports.
The table lists the following for iSCSI CHA packages:
• Port Name: Displays iSCSI port names
• IP Address: Displays the iSCSI port IP addresses
• Subnet Mask: Displays subnet masks
• Gateway: Displays gateway addresses
• iSCSI Name: Displays iSCSI port names
• iSCSI Alias: Displays iSCSI port aliases
• Port Number: Displays iSCSI port numbers
• Keep Alive Timer: Displays the keep-alive timer values in seconds
• INS Server: Indicates whether you can register the iSCSI port in the ISNS server
• Enable: You can register the iSCSI port
• Disable: You cannot register the iSCSI port
• iSNS IP Address: Displays the IP address of the ISNS server
• iSNS Port No: Displays the TCP port number of the iSNS server
• MAC Address: Displays the iSCSI port media access control (MAC) addresses
Table 13 Channel adapter package icons for Port operations
Icon Status
A short-wave CHA package in standard mode (Fibre Channel)
or
A short-wave iSCSI CHA package
A long-wave CHA package in standard mode
A short-wave CHA package in high-speed or high-speed (2 port) mode
A long-wave CHA package in high-speed or high-speed (2 port) mode
