Configuring iLO 2 62
F3
0
d
~
4.
Click Apply to save changes.
This feature can also be configured using scripting or command lines. For more information, see the HP
Integrated Lights-Out Management Processor Scripting and Command Line Resource Guide.
Network
The Network Settings and DCHP/DNS tabs of the Network section enable you to view and modify
network settings for iLO 2.
Only users with the Configure iLO 2 Settings privilege can change these settings. Users that do not have
the Configure iLO 2 Settings privilege can view the assigned settings.
To change network settings for iLO 2:
1.
Log in to iLO 2 using an account that has the Configure iLO 2 Settings privilege. Click
Administration>Network.
2.
Select Network Settings or DHCP/DNS.
3.
Change the settings as needed.
4.
After completing any parameter changes, click Apply to complete the changes.
iLO 2 restarts, and the connection of your browser to iLO 2 terminates. To reestablish a connection, wait
60 seconds before launching another browser session and logging in.
Network Settings
The Network Settings page displays the NIC IP address, subnet mask, and other TCP/IP-related
information and settings. From the Network Settings screen, you can enable or disable DHCP and
configure a static IP address for servers not using DHCP. All users can view the network settings, but only
users with the Configure iLO 2 Settings privilege can change these settings. To access the Network
Settings page, click Administration>Network>Network. The Network Settings page appears with the
following information and settings:
•
NIC enables you to set the iLO 2 NIC to Enabled, Disabled, or to Shared Network Port.
o
Enabled—Enables the primary iLO 2 network interface.
o
Disabled—Disables the iLO 2 network interface. You must use the iLO 2 RBSU or other host-
based scripting utility to re-enable the network interface.
o
Shared Network Port—Enables networking using the designated host Ethernet port. The port
appears as two separate Ethernet MACs and IP addresses on the network. See the section, "iLO
2 Shared Network Port (on page
)" for more information.
•
DHCP enables you to select static IP (disabled) or enables the use of a DHCP server to obtain an IP
address for the Integrated Lights-Out 2 subsystem.
You cannot set the iLO 2 IP Address and Subnet Mask if DHCP is enabled. Disabling DHCP enables
you to configure the IP address. The IP Address field also appears on the DHCP/DNS Settings page
for convenience. Changing the value on either page changes the DHCP setting.
•
IP Address is the iLO 2 IP address. If DHCP is used, the iLO 2 IP address is automatically supplied. If
not, enter a static IP address. The IP Address field appears on the DHCP/DNS page for
convenience. Entering values in the field on either page changes the IP address of the iLO 2.
