• Storage tab—Displays the unallocated space, used space, free space on the volume, and the
following storage allocation details:
Table 26 Storage tab—Application server volume properties
Value Property
Name of the application server where the volume resides. Application Server Host Name
Name of the volume on the application server. Volume is located
on the iSCSI LUN exported by ASM. Application Server Volume -
Name
Status of the volume on the application server. Application Server Volume -
Status
Indicates if the volume on the application server is configured with
exclusive storage. See “
Table 6 ” on page 27 for more information.
Application Server Volume -
Exclusive Storage
The RAID level to which the volume on the application server is
configured. See “
Customizing RAID levels ” on page 29 for more
information.
Application Server Volume -
RAID Level
The RAID stripe size to which the volume on the application server
is configured. See “
Table 6 ” on page 27 for more information.
Application Server Volume -
RAID Stripe Size
Speeds up reads when enabled. This setting is determined by the
storage array, not ASM. Application Server Volume -
Read Cache
Speeds up writes when enabled. This setting is determined by the
storage array, not ASM. Application Server Volume -
Write Cache
The number of hot spares with which the volume on the application
server is configured. See “
Table 6 ” on page 27 for more
information.
Application Server Volume -
Number of Hot Spares
Path the volume is mounted on. Application Server Volume -
Mount Paths
Storage Utilization View
Storage Utilization View displays the allocated storage values for specific applications and the shared
folders pool, the unallocated storage value, and the storage value for data not managed by ASM in
a pie chart.
• In the Actions pane, select Storage Utilization View.
The storage value for each application hosted, the shared folders pool, unallocated storage, and data
not managed by ASM is displayed according to its percentage of total capacity, using colors selected
in the Color Options window (see
Changing color settings on page 17).
The total capacity of your HP All-in-One Storage System is divided into the following areas:
• Exchange—Storage allocated to host Exchange storage group components.
• Shared Folders—Storage allocated to host shared folders.
• SQL Server—Storage allocated to host SQL Server database components.
• User-defined—Storage allocated to host user-defined applications.
• Unmanaged—Storage used by data that is not managed by ASM.
