Click the Expand tree icon next to each application server to view the used and allocated storage
properties for the volume and application components. Click the Collapse tree icon next to an expanded
application server to hide the volume and application component storage properties.
To view all the storage properties for an item listed in the content pane, see Accessing application
server properties .
Accessing application server properties
When Application Server View is selected in the Actions pane, you can view the storage status, alerts,
and properties for the following:
• Volumes created on the iSCSI LUNs (logical disks) exported by ASM to the application servers
• Shared folders and application components (same information displayed on Application View)
Do one of the following:
• Select the item in the content pane and then click Properties in the Actions pane.
• Right-click the item in the content pane and select Properties.
See “ Accessing application and shared folder properties ” on page 48 for descriptions of shared
folder and application component properties.
Accessing properties for application server volumes
ASM provides properties information for application server volumes created on the iSCSI LUNs
exported by ASM to the application server.
1. In the Actions pane, select Application Server View.
2. Do one of the following:
• Select an application server volume in the content pane and then click Properties in the Actions
pane.
• Right-click an application server volume in the content pane and select Properties.
3. Click one of the following tabs:
• General tab—Displays the name of the volume on the application server, the volume type,
and status:
Table 25 Operating status—Application server volume properties
Value Status indicator
The storage is online. OK
See the Alerts list for more information. See “ Table 27 ” on page
64 for alert descriptions.
Warning
See the Alerts list for more information. See “ Table 27 ” on page
64 for alert descriptions.
Critical
Monitoring storage 60
