Value
Property
Unused storage space on the logical disk that is not allocated.
Free Space
Table 24 Storage tab—HP All-in-One Storage System volume properties
Value
Property
Name of your HP All-in-One Storage System.
Storage Server Host Name
Name of the volume on your HP All-in-One Storage System.
Storage Server Volume - Name
Status of the volume on your HP All-in-One Storage System.
Storage Server Volume - Status
Indicates if volume is configured with exclusive storage. See “
” on page 27 for more information.
Storage Server Volume - Exclusive
Storage
The RAID level to which the volume is configured. See “
” on page 29 for more information.
Storage Server Volume - RAID
Level
The RAID stripe size to which the volume is configured. See “
” on page 27 for more information.
Storage Server Volume - RAID
Stripe Size
Speeds up reads when enabled. This setting is determined by the storage
array, not ASM.
Storage Server Volume - Read
Cache
Speeds up writes when enabled. This setting is determined by the storage
array, not ASM.
Storage Server Volume - Write
Cache
The number of hot spares with which the shared folder's storage is
configured. See “
” on page 27 for more information.
Storage Server Volume - Number
of Hot Spares
Path on which the volume on your HP All-in-One Storage System is
mounted.
Storage Server Volume - Mount
Paths
•
Warning Threshold tab—Allows you to change the percent full warning threshold value for the
user-defined application.
•
Data Protection tab—Allows you to schedule backups or run a backup of the user-defined
application data, or restore the user-defined application data from a backup. It also allows you
to schedule snapshots or take a snapshot of the user-defined application data, expose a snapshot,
or revert the user-defined application data to a past snapshot.
Application Server View
Application Server View lists your HP All-in-One Storage System and the application servers with
storage hosted on your HP All-in-One Storage System. Expand HP All-in-One Storage System to display
the top-level shared folders on your HP All-in-One Storage System. Expand the application servers
listed to display the application server volumes and the applications hosted on the volumes.
•
In the Actions pane, select Application Server View.
•
To view the properties for all application servers with storage hosted on your HP All-in-One Storage
System, select All from the Filters drop-down menu, located at the top of the content pane. See
on page 15 for more information.
Application server properties are displayed in order of hierarchy in an expandable and collapsible
view. For example, all the volumes created on the iSCSI LUNs (logical disk) exported by ASM to the
application server are displayed under the application server, and all the application components
hosted from the application server are displayed under the application server.
