Description
Menu
Displays the allocated storage values for specific applications and the
shared folders pool, the unallocated storage value, and the storage value
for data not managed by ASM in a pie chart. See “
” on page 61 for more information.
Storage Utilization View
Opens the Task Viewer, where you can view the:
Tools > Task Viewer
•
Status of tasks completed or scheduled to run in the future.
•
All tasks that failed and the errors reported.
The Task Viewer also allows you to cancel running and scheduled tasks.
See “
Monitoring task completion status
” on page 34 for further
information.
Displays the Configure Options window, where you can:
Tools > Display Options
•
Change the colors used in the content pane to display the different
types of storage, volumes, and servers.
•
Change the scaling used in the content pane so the size at which
each application area or shared folder is displayed is proportional
to the size of its allocated storage space, or to display them all at
equal size.
See “
Defining user interface options
” on page 17 for further information.
Refreshes the content pane.
Refresh
Opens a storage-allocation wizard that helps you allocate and configure
storage space on your HP All-in-One Storage System.
Any one of the following items:
•
Host an Exchange Storage
Group
•
Create a Shared Folder
•
Host a SQL Server Database
•
Host a User-Defined Application
This is an MMC command. See the Microsoft Management Console
online help. To open MMC online help, click Help in the Actions pane.
View > Customize
Opens online help for ASM.
Help
Opens the Allocate Space Wizard where you can change the following
storage configurations for the item selected in the content pane:
Allocate Space
•
Size of allocated storage
•
Percentage full warning threshold
•
Enforced allocated limit (shared folders only)
See “
” on page 27 for more information.*
Removes the application component or user-defined application selected
in the content pane from view. Application areas removed from view
Remove from View
can no longer be managed or monitored using ASM, but the application
storage remains hosted on your HP All-in-One Storage System.See
“
Removing application areas from view
” on page 42 for more
information.*See “
Restoring application areas to view
instructions on how to return an application area to view.
Opens the Properties window where you can view the properties for the
item selected in the content pane. See “
Accessing application and shared
Properties
Overview
