5 Monitoring storage
ASM provides storage-management functions so you can quickly view used and allocated storage,
and percent full warning thresholds settings for application and shared folder storage on your HP
All-in-One Storage System. You have a choice of these views for the content pane:
, page 47—Monitoring the overall used and allocated storage values for specific
applications and shared folders (such as Exchange or SQL Server storage)
, page 56—Monitoring the used and allocated storage values for the logical disks
and volumes on your HP All-in-One Storage System that ASM created to host application storage
and shared folders.
, page 59—Monitoring the application servers with storage hosted on
your HP All-in-One Storage System.
, page 61—Monitoring the allocated storage values for specific applications
and the shared folders pool, the unallocated storage value, and the storage value for data not
managed by ASM.
Views are selected from the Actions pane.
You can also quickly view storage status on the content pane. Status icons for warnings and critical
conditions are displayed on top of icons in the content pane when storage status changes from OK
to Warning or Critical. See “
” on page 64 for more information on status icons.
NOTE:
Select an item in the content pane and then click
Properties in the Actions pane to view any alerts for the
item. See “
” on page 64 for alert descriptions and troubleshooting information.
Application View
Application View displays the used and allocated storage space, and storage status of applications
and shared folders hosted on your HP All-in-One Storage System in the content pane.
•
In the Actions pane, select Application View.
•
To view all the application storage and shared folders hosted on your HP All-in-One Storage
System in the content pane, select All from the Filters drop-down menu, located at the top of the
content pane. See
on page 15 for more information.
Application storage properties are displayed in order of hierarchy in an expandable and collapsible
view.
Click the Expand tree icon next to each application to view the used and allocated storage properties
for the hosted application components. Click the Collapse tree icon next to expanded applications
to hide the application component storage properties.
To view all the storage properties for an item listed in the content pane, see
.
All-in-One Storage Manager
