Chapter 2. Installation
61202.153L3-1 Express XRT User Guide 7
8. Power on the computer.
9. Go to the
Express XRT Software Installation section.
Figure 2-2
Standard ISDN Internet/Remote Access Application
Express XRT Software Installation
The installation procedure varies depending on whether you are
using a PC or a Macintosh. If the computer is not already on, pow-
er on the computer, start Microsoft Windows (for a PC) and use
the following installation procedure that applies to your comput-
er and operating system.
ISDNU
OFF
ON
2 1 MODEM RS232 POWER 1 2 3 4
RS-232 Cable
COM
Port
ISDN Telephone
Wall Jack
AnalogTelephone
Rear View of PC
Express XRT
FAX Machine
AC Outlet
RJ-45 to RJ-11
Telephone Cable
