Appendix E
Connector Pinouts
Figure E-1
RS-232 Interface
Table E-A
RS-232 Interface
Pin
Name
I/O
Description
1
Shield
I/O
Shield for cable
2
TD
I
Transmitted Data
3
RD
O
Received Data
4
RTS
I
Request to Send
5
CTS
O
Clear to Send
6
DSR
O
Data Set Ready
7
SG
I/O
Signal Ground
8
CD
O
Carrier Detect
PIN 13
PIN 1
PIN 25
PIN 14
FEMALE
