Network Management Card User’s Guide 26
Network Management Card
Device Manager Menus
Introduction
Overview Two Device Manager menus can appear.
• A UPS menu, which uses the UPS model for its name, provides
the options that you use to manage the UPS . For more
information about this menu, see UPS menu options below.
• An Environment menu, which appears only present when an
Environmental Monitor is present, provides options that you use
to manage the Environmental Monitor. For more information
about this menu, see
Environment Menu on page 43 .
UPS menu options The UPS menu options, and the information provided by those options,
vary by UPS model . In addition, there are differences between the UPS
menu in the Control Console and the UPS menu in the Web Interface.
One major difference is the UPS menu in the Web Interface includes a
PowerChute ® option, which allows you to use APC’s PowerChute
network shutdown utility.
For information about the PowerChute ® option, which is only available
in the Web Interface, see PowerChute® (UPS PowerChute network
shutdown) on page 39 . For information about the UPS menu options
available in both the Control Console and the Web Interface, see the
following:
• UPS Status on page 27
• UPS Diagnostics on page 31
• UPS Control on page 33
• UPS Configuration on page 34
• Module Status (Symmetra or Symmetra 3 Phase UPS) on
page 38
• Scheduling (UPS Shutdown) on page 41
Note: A Silcon DP300E series UPS has no Diagnostics or
Scheduling options. In addition, although the Control
option appears in the UPS menu, that option is disabled
(Control Console) or has no actions available (Web
Interface).
