Avaya 3600 - Manual (Page 39)

Avaya, Inc. Configuration and Administration—AVAYA 3616/3620/3626 WT
Avaya CCMS IP, Avaya Call Server, with Avaya 4612 IP Telephone Emulation
21-300352, Issue 2, July 2005 Page 39
The Wireless Telephone relies on the PBX’s response to a Button Request
message to allocate
LINE
and
FCN
keys to the appropriate list, as well as
to supply correct labels for the keys. If the PBX fails to respond, or if the
response cannot be properly parsed, the following default behavior is
applied:
If the IP Office mode is enabled, six default keys are assigned under the
LINE
key, and are labeled L/F 01 through L/F 06. These keys send the
same codes as P1 through P6 on the 4606/4612 terminal.
If the IP Office mode is disabled, an additional six keys labeled L/F 07
through L/F 12 are assigned under the
FCN
key, and send the same key
codes as P7 through P12 of the 4612 terminal.
