Canon VB-C60 - Manual (Page 72)

2-6
Launching VBAdmin Tools
How to Launch
1. Double-click the [VBAdmin Tools] icon on the desktop, or select [WebView Livescope]
[VBAdmin Tools] from [Programs] in the [Start] menu.
Starting from the Desktop Icon Or starting from the [Start] menu
2. The dialog box for specifying the camera to connect to appears.
To use VBAdmin Tools, you must connect to the camera first. Enter each item and then click
[OK].
(1)Host name ( P. 1-8, P. 1-10)
Specify the IP address or host name of the camera.
(2)User name
Enter the Administrator account "root" set for the camera.
(3)Password ( P. 1-7)
Enter the Administrator password (the factory setting is "VB-C60" for both VB-C60 and
VB-C60B).
(4)HTTP port ( P. 1-33)
The default is "80".
(5)Setting page URI
The Setting page URI set for this camera is fixed to "admin" and cannot be changed.
(1)
(4)
(3)
(2)
(5)
(6)
(7)
