Brother HL-L9200CDWT - Manual (Page 92)

85
3
3
Control panel overview
3
This is a Touchscreen LCD with an electrostatic Touchpanel that only displays the LEDs when they can be used.
1 1.8 in. Touchscreen LCD (Liquid Crystal Display)
This is a Touchscreen LCD. You can access the menus and options by pressing them when they are
displayed on the screen.
2 Touchpanel:
The LEDs on the Touchpanel only light up when they are available for use.
 Back
Press to go back to the previous menu level.
 Home
Press to return to the Home screen.
 Stop
Press to cancel an operation when illuminated red.

s
or t
Press to display the previous or next page. The Up and Down Arrows do not light up when there is only
one page.
3 Power On/Off
Press to turn on the machine. Press and hold down to turn off the machine.
The Touchscreen LCD displays Shutting Down and stays on for a few seconds before going off.
General Information
3
1
2
3
