Character
PV screen
Auxiliary screen
Designation
Description
Initial value
4
□
to
□
□
to
□
Set an upper limit
for event output 1
to 6
Set a lower limit
for event output 1
to 6
Thermocouple input
Setting range: -199 to 999 or -199.9 to 999.9
Setting unit:
°C
Resistance bulb input
Setting range: -199 to 999 or -199.9 to 999.9 or
-199.99 to 999.99
(when the input type is , ,
or )
Setting unit:
°C
Current and voltage inputs
Setting range: -19999 to 99999
The decimal place can be set to a
desired position.
Setting unit:
digit
CH2 only
Potentiometer input
Setting range: -199.9 to 999.9
Setting unit:
%
5
□
to
□
Set a sensitivity for
event output 1 to 6
Thermocouple input
Setting range: 0 to 999 or 0.0 to 999.9
Setting unit:
°C
Resistance bulb input
Setting range: 0 to 999 or 0.0 to 999.9 or 0.00 to
999.99
(when the input type is , ,
or )
Setting unit:
°C
Current and voltage inputs
Setting range: 0 to 99999
The decimal place can be set to a
desired position.
Setting unit:
digit
CH2 only
Potentiometer input
Setting range: 0.0 to 999.9
Setting unit:
%
6
□
to
□
Set a delay timer
for event output 1
to 6
Setting range: 0 to 9999 seconds
