TOHO ELECTRONICS TTM-509 - Manual (Page 48)

TOHO TOHO ELECTRONICS INC.
DWG. No.
45-4199-E
PAGE
48/66
Character
PV screen
Auxiliary screen Designation Description Initial value
38 □ch
 Set a control
sensitivity for the
main output Thermocouple input
Setting range: 0 to 999 or 0.0 to 999.9
Setting unit:
°C

40 □ch
 Set a control
sensitivity for the
auxiliary output Resistance bulb input
Setting range: 0 to 999 or 0.0 to 999.9 or 0.00 to
999.99
(when the input type is , ,
or )
Setting unit: °C
Current and voltage inputs
Setting range: 0 to 99999
The decimal place can be set to a
desired position.
Setting unit: digit
* The differential gap (sensitivity) of the potentiometer
is set with the dead band.

39  ch
 Position the OFF
point of the main
output Thermocouple input
Setting range: -199 to 999 or -199.9 to 999.9
Setting unit:
°C

41  ch
 Position the OFF
point of the
auxiliary output Resistance bulb input
Setting range: -199 to 999 or -199.9 to 999.9 or
-199.99 to 999.99
(when the input type is , ,
or )
Setting unit: °C
Current and voltage inputs
Setting range: -19999 to 99999
The decimal place can be set to a
desired position.
Setting unit: digit

