4.3.2 Initial setting
 
MODE key
Select an initial setting
 

MODE key
Select an initial setting
channel

 
MODE key
Set an input type
 
 
MODE key
Set a decimal point

 
MODE key
Set a PV correction gain

 
MODE key
Set a PV correction zero
point

 
MODE key
Set a PV filter

 
MODE key
Set whether to enable
square-root operations
 
 
MODE key
Set whether to perform
polygonal line approximation

 
MODE key
Set a display range of
deviations
Red Green
CH key
Red
Green
 

MODE key

 
MODE key
 
 
MODE key

 
MODE key

 
MODE key

 
MODE key

 
MODE key
 
 
MODE key

 
MODE key

 
MODE key
Set the buzzer
CH key
CH key
CH key
CH key
CH key
CH key
CH key
CH key
