4.3 Setting mode
Press the MODE key for 3 seconds while in the operation mode. The system will then switch to
the "Select the setting mode" screen.
While in that state, use the ▲ and ▼ key to select a setting category and press the MODE key to
enter the setting mode for a specific category.
Main power
supply OFF
Initial screen displayed (4 seconds)
Operation mode
Select the setting mode
OUT6
setting
OUT5
setting
OUT4
setting
OUT3
setting
OUT2
setting
OUT1
setting
Control
setting
Initial
setting
Priority
screen
Power ON
4 seconds later
MODE key at least 2 seconds
Determine a setting
type selection
Set communi-
cations 1
DI3 setting DI2 setting DI1 setting
Transmission
setting
DI4 setting
Set communi-
cations 2
Set the timer Set logging
Priority
screen 1
Priority
screen 2
Priority
screen 3
CT
CH1 polygonal
line
approximation
CH2 polygonal
line
approximation
Log contents Set keys
Bank setting mode
MODE key at least 6 seconds
(passing through "Select the setting mode")
