TOHO TOHO ELECTRONICS INC.
DWG. No.
45-4199-E
PAGE
42/66
Character
PV screen
Auxiliary screen Designation Description Initial value
4 □ch
 Set a decimal place Thermocouple input: /
Resistance bulb (including a 4-wire type):
//
*For , set an input type: In the range from
-120.00 to 120.00 only
Current and voltage: Set it to a desired digit.
Potentiometer:
Fixed at 

5  ch
 Set a PV
correction gain Setting range: 0.500 to 2.000
Setting unit: Times 
6  ch
 Set a PV
correction zero
point Thermocouple input
Setting range: -199 to 999 or -199.9 to 999.9
Setting unit:
°C
Resistance bulb input
Setting range: -199 to 999 or –199.9 to 999.9 or
–199.99 to 999.99
(when the input type is ,,
or )
Setting unit: °C
Current and voltage inputs
Setting range: -19999 to 99999
The decimal place can be set to a
desired position.
Setting unit: digit

Potentiometer input
Setting range: -199.9 to 999.9
Setting unit:
%
7  ch
 Set a PV filter 0.0 to 99.9 seconds 
8  ch
 Set whether to
perform
square-root
operations : Enable operation
: Disable operation 
9 □ch
 Set whether to
perform polygonal
line approximation : Enable polygonal line approximation
: Disable polygonal line approximation 
