Character
PV screen
Auxiliary screen Designation Description Initial value
18  ch
 Set an AT
sensitivity Thermocouple input
Setting range: 0 to 999 or 0.0 to 999.9
Setting unit:
°C
Resistance bulb input
Setting range: 0 to 999 or 0.0 to 999.9 or 0.00 to
999.99
(when the input type is, ,
or )
Setting unit: °C
Current and voltage inputs
Setting range: 0 to 99999
The decimal place can be set to a
desired position.
Setting unit: digit

CH2 only
Potentiometer input
Setting range: 0.0 to 999.9
Setting unit:
%
19 □ch
 Set a proportional
band for the main
output Setting range: 0.0 to 200.0
Setting unit: % of  ch to  ch 
20 □□ch
 Set an integration
time for the main
output Setting range: 0 to 3,600 seconds 
21 □□ch
 Set a derivative
time for the main
output. Setting range: 0 to 3,600 seconds 
22 □ch
 Set a proportional
cycle for the main
output Setting range: 1 to 120 seconds 
23  ch
 Anti-reset windup Setting range: 0.0 to 100.0 (-10.0 to -110.0: in analog
output)
Setting unit: %

24  ch
 Set an upper limit
for the main output
operation amount
limiter Setting range: Set a lower limit for the operation amount
limiter to 100.0 (-110.0: in analog output)
Setting unit: %

25  ch
 Set a lower limit
for the main output
operation amount Setting range: Set the system to 0.0 (-10.0: in analog
output) to an upper limit for the operation
amount limiter
Setting unit: %

26  ch
 Manual reset Setting range: 0.0 to 100.0
-100.0 to 100.0 (heating/cooling)
Setting unit: %

