Character
PV screen
Auxiliary screen Designation Description Initial value
42 □ch
 Set a dead band Thermocouple input
Setting range: -100 to 100 or -100.0 to 100.0
Setting unit:
°C
Resistance bulb input
Setting range: -100 to 100 or -100.0 to 100.0 or
-100.00 to 100.00
(when the input type is , ,
or )
Setting unit: °C
Current and voltage inputs
Setting range: -1000 to 1000
The decimal place can be set to a
desired position.
Setting unit: digit

CH2 only
Potentiometer input
Setting range: 0.0 to 999.9
Setting unit:
%
In the case of a potentiometer, this setting will become a
differential gap (sensitivity) between the open and the
closed output.
