6 Data transmission
BU 0070 GB Subject to technical alterations 31
6.4.2 Object description
Object 603F error code
Code Error description Code Error description
0 No error 6000 Device software
1000 General error 6310 Parameter loss
2200 Internal device current 7112 Brake chopper overcurrent
2310 Constant output overcurrent 7120 Motor
3110 Mains overvoltage 7300 Sensor
3120 Mains undervoltage 7305 Incremental encoder 1
3130 Phase failure 7306 Incremental encoder 2
3210 Internal device overvoltage 7310 Speed sensor
3230 Charging error 7320 Position sensor
4210 Device overheating 8100 Communication monitoring
4310 Drive overheating 8300 Torque controller
5110 Low voltage supply 8400 Speed controller
5300 Operation unit 8612 Reference limit
5510 RAM data memory 9000 External error
5520 Eprom data memory
5530 EEPROM data memory
Object 6040 control word and 6041 status word
6040 control word 6041 status word
Bit InterBus significance Bit InterBus significance
0 Switch on 0 Standby
1 Block voltage 1 Switched on
2 Emergency stop 2 Operation enabled
3 Enable operation 3 Error
4 Block run-up encoder 4 Current blocked
5 Stop RUE 5 Emergency stop
6 RUE zero 6 Switch-on block
7 Reset error 7 Warning
8 Reserve 8 0
9 Reserve 9 Remote
10 Reserve 10 Setpoint reached
11 Rotary direction (0=right) 11 Limit value*
12 Free 12 0
13 Free 13 0
14 Free 14 Rotation direction (0=right)
15 Free 15 0
*Min or max value reached
