NORDAC InterBus Operating Manual
18 Subject to technical alterations BU 0070 GB
Parameter Setting value / Description / Note Available in Option
P546 Function bus - Setpoint 1 Always visible
0 ... 24
[ 1 ]
valid for SK
5xxE
In this parameter, a function is allocated to the output setpoint 1 during bus actuation.
NOTE: Further details can be found in the respective BUS operating instructions or in the
description of P400.
0 = Off
1 = Setpoint frequency (16 Bit)
2 = Torque current limit (P112)
3 = Actual frequency PID
4 = Frequency addition
5 = Frequency subtraction
6 = Current limit (P536)
7 = Maximum frequency (P105)
8 = Actual PID frequency limited
9 = Actual PID frequency monitored
10 = Torque servo mode (P300)
11 = Torque lead (P214)
12 = Reserved
13 = Multiplication
14 = PI process controller actual value
15 = PI process controller setpoint
16 = PI process controller lead
17 = Digital In Bits 0...7
18 = Reserved
19 = Status output (P434/441/450/455=38)
20 = Value analog output (P418=31)
21 = … 24 reserved
P547 (P) Bus setpoint 2 Always visible
0 ... 20
[ 0 ]
valid for
SK 300/700/750E
In this parameter, a function is assigned to the delivered setpoint 2 (SW2) for bus control.
0 = Off
1 = Setpoint frequency (16 Bit)
2 = Torque current limit (P112)
3 = Actual frequency PID
4 = Frequency addition
5 = Frequency subtraction
6 = Current limit (P536)
7 = Maximum frequency (P105)
8 = Actual PID frequency limited
9 = Actual PID frequency monitored
10 = Torque servo mode (P300)
11 = Torque lead (P214)
12 = Control terminals PosiCon (only with
PosiCon option)
13 = Multiplication
14 = PI process controller actual value
15 = PI process controller setpoint
16 = PI process controller lead
17 = Digital In Bits 0...7
18 = Curve travel calculator
19 = Status output (P434/441/450/455=38)
20 = Value analog output (P418=31)
21 = … 24 reserved
