Frequency inverters – Migration Guide SK 700E to SK 5xxE
18 MI 0700 GB-0414
SK 700E SK 700E
Features /
Performance range
SK 5xxE
Name Name
SK 700E-xxx-340- X (-RS2) *
+ CANopen Bus
SK TU1-CAO
Standard
Performance 1.5 kW to 7.5 kW
+ incl. mains filter *
+ optional with int. RS232 interface *
+ CAN connection via 9-pole sub-D
socket
+ Connection of external 24 V supply
voltage
+ CANopen addressing with rotary coding
switch
+ Baud rate adjustment with rotary coding
switch
+ DIP switch termination resistor
SK 500E-xxx-340-A
incl. mains filter Class C2 **
+ RS232 interface
+ CANopen Bus
SK TU3-CAO
Standard
Performance 11.0 kW to 160.0 kW
+ with/without mains filter *
+ optional / with int. RS232 interface *
+ CAN connection via 9-pole sub-D
socket
+ Connection of external 24 V supply
voltage
+ CANopen addressing with rotary coding
switch
+ Baud rate adjustment with rotary coding
switch
+ DIP switch termination resistor
SK 515E-xxx-340-A
with mains filter Class C2 **
+ RS232 interface
+ CANopen Bus
SK TU3-CAO
*
(-RS2) with additional optional/integrated RS232 interface on SK 700E frequency inverters ≤ 22.0 kW.
The token X represents A (with integrated mains filter) on SK 700E frequency inverters ≤ 22.0 kW
O (without integrated mains filter) on SK 700E frequency inverters ≥ 30.0 kW
** The cable lengths must be taken into account because the mains filter characteristics can vary.
***
RJ45 WAGO adapter module (278910300) to connect the CAN cable with an RJ45 western plug to the SK 5xxE,
alternatively crimp an RJ45 plug to the CAN cable.
Table 5: Overview of SK 5xxE performance levels for CAN and CANopen
