3
SECTION 1
INTRODUCTION AND DESCRIPTION
SECTION 1.1: UNIT DESCRIPTION:
The single input and the dual input intelligent process
meters features 5 ½ digit resolution, 6 digit display, high speed, 5 front key
operation and a NEMA 4X, industrialized aluminum case. One Form A relay is
provided standard for use as an Alarm output or shunt cal relay. The IPM500
emphasizes the features required in today’s applications, especially scaling of the
meter to display in engineering units. Three methods are provided to scale the
meter: No calculation scale and offset, load calibration and shunt calibration only.
Stock #'s
:
FSH00248- one input channel
FSH00947- two input channels; Options C, H, P, T installed
Options:
"C" 3 Form C Relays
"H" Analog & Excitation Output
"P" Excitation Supplies 10/24 VDC
"T" Serial RS-232C Communication
Ordering Example:
3720A-01CH Single Input with 3 Relays, Analog output,
and Screw Terminals.
