11
• When entering numeric data, it decrements the numeric value of
the flashing digit by one with each push.
4. EXIT KEY
• If at a Main branch prompt (CODE, CHAN, OUTPUT, DISPLY
or SPEC), it exits to you back to RUN mode.
• If in a programming branch, it returns you to Main branch
prompt.
NOTE: It does note store data to memory on its return.
ENTER key should be pushed first to store selected entry,
then EXIT key.
5. ENTER KEY ( on flow chart indicates to use this key)
• Enters selected Main program branch.
> Moves you down in the program branch menu.
> Menu steps can be skipped by repeatedly pushing ENTER
key till desired menu step is reached.
• Enters selected choices, numeric data or decimal point, it stores
the value and advances to next step in the program menu.
SECTION 3.3: RUN MODE KEY FUNCTIONS
A. Entering SETUP
Push and hold SETUP key for 4 seconds. Meter will first
display “SET CH” then display “CODE” or flash “SETUP then
display “CHAN”.
• “CODE” is flashed with 00 if a lockout code has been
under the Main program branch heading SPEC, CODE
menu.
> The preset lockout must be entered at this time. If
wrong code is entered or if no code is entered within
20 seconds, meter will return to RUN mode.
> Upon correct lockout code entry, meter enters the
SETUP mode.
> The unmarked yellow LED just above the Down/F4
key will light, indicating you are in the SETUP mode.
• If no lockout code, “SETUP” flashed then “CHAN”
displayed, indicating you have entered the SETUP mode.
