15
D. F1, F2, F3 and F4 keys
The RUN mode keys (F1-F4) functions are selected in the
SETUP mode under the Main program branch heading
SPEC. The functions are described under the SPECIALS
FEATURES PROGRAMMING BRANCH section of the
manual (See pg. 26). The following are the available
selections.
• "ALARM 1" through "ALARM 4"
• "TARE1", "TARE 2" and "TARE 3"
• "RESET"
• "CHAN 1, 2 or 3"
• "PEAK 1"
• "PEAK 2"
• "SCALE 2"
• "NET"
• "SHUNT" (display/calibration)
SECTION 3.4: PROGRAMMING TIPS
SELECT Key
This represents SELECT key on flow charts
ENTER Key
This represents ENTER key on flow charts
Numeric values are entered by;
• Entering a number in flashing digit with the “UP” and “DOWN”
keys.
• Advance to the next digit using SELECT key. Enter value and
advance using ENTER key.
ENTER key sets number into memory and advances to next program.
EXIT key :
1. From MAIN BRANCH heading, takes you back to run mode
2. From PROGRAM BRANCH, takes you back to MAIN
BRANCH heading you are in.
TIMED OUT EXITS:
1. If no key is pushed within 20 seconds while at CODE or main branch
heading, meter will automatically exit back to run mode.
