12
If no key is pressed within 20 seconds, meter will return
to RUN mode.
B. If SETUP key pushed and released meter will enter select
channel program.
• “SET CH” (SET CHANNEL) will be display.
> Push F1 to select Channel 1 for display
> Push F2 to select Channel 2 for display
(3722A only)
> Push F3 to select Channel 3 for display
(3722A only)
C. USER PROGRAMMABLE MENU LOCKOUT.
To enter, push and hold SETUP key, then enter lockout code
“ 55”. This program allows user to disable/lockout the following
menus from the SETUP program. When the menus are
programmed to be locked, the unit will display “DISABL” when
you try to enter the menu.
NOTE: A code # must be preprogrammed under
SPEC, CODE to get the prompt for the code value.
To disable one or more of the selections add the values from the table and
enter that number. If 0 is entered, all programs under that heading are
enabled.
• “LEVEL1” is flashed with current selected number, valid
values 0-15
0 Don’t Skip any branches
1 Skip all channel programs "CHAN"
2 Skip all output programs "OUTPUT"
4 Skip all display program "DISPLY"
8 Skip all special programs "SPEC"
Example: Enter number 12 to skip DISPLY
and SPEC branches from normal setup
selections.
