21
values are the result of the above selected math formulas. Push
ENTER key to advance.
c. "DEC PT" selects decimal point. Push SELECT key for
displaying decimal point selections and ENTER key to enter
choice.
d. "In LO", enter in low input value
e. "DSP LO", (display low) enter in display value corresponding to
low input value.
f. "In HI", enter in high input value.
g. "DSP HI", (display high) enter in display value corresponding to
high input value.
h. “ OFFSE” Enter an offsetting factor from –9999 to 9999, which
is applied after the above scaling.
SECTION 3.8: OUTPUT SETUP PROGRAMMING
BRANCH
Push SELECT key to choose which output you wish to program. Then
press ENTER key.
"AL AR" is the 4 alarm output setups; "ANALOG" is analog output
setup
1. ALARMS
This setup menu programs the 4 alarms.
NOTE: Relays 1 through 3 are optional FORM “C” relays
and located on the option/top board.
Relay 4 is standard FORM “A” relay and located on the
main/bottom board.
a. "AL AR" selects which alarm is to be programmed. Use
SELECT key to view choices of alarms 1 through 4. Use the
ENTER key to enter choice.
Note: 1. Each alarm is treated completely
independent thus allowing all 4 to be programmed
with same channel or different channels
controlling one alarm.
