30
10 seconds. Meter then returns to
"SPEC" branch heading.
SECTION 4 OPTIONS
OPTION C:
• 3 form C (single pole double throw) relays rated at 5 amp @
240VAC, 5amps @ 30VDC.
• Located on the option/top printed circuit board
OPTION H:
• Analog output with menu selection of 0-20mA, 4-20mA, 0-
5VDC, 0-10VDC and +5/-5VDC
• Update rate of 25/second (3720A)
• Resolution - 16 bit D/A
• Located on the option/top printed circuit board
OPTION P:
24VDC @ 150mA
Accuracy: .5%
10VDC @ 250mA supply
Accuracy: .5% (adjustable)
OPTION T:
• Serial RS-232C Communication.
