DevCom2000 User Manual
MAN-1010 7/19/2010 Our Quality Management System is Page 35
ISO 9001:2008 Certified
Step Action
To get details about a configuration, select the desired
configuration and double click it. The details will be displayed
below.
4 You can change the desired Tag by editing the Configuration
File Tag box.
5 Press the “Write” button to write device configuration. The
device must be the same type as the configuration file. If they
are different, the write operation will be aborted.
6 You can view the PDF file for the configuration file by double
clicking on the desired configuration and pressing “View”.
7 You can delete configurations by double clicking on the desired
configuration and pressing “Delete”.
6.10
Customizing PDF File Output
HART Device configurations can also be saved to disk as PDF Files to document the device. The header, footer,
and technician name can be entered to customize the PDF file to make it into a configuration report.
To customize the PDF output, perform the following steps:
Step Action
1 Press the “PDF Setup” button on Document Device Dialog Box:
2 The PDF Setup Dialog box is displayed:
