Page 97: Performance data
EasiCool™
Precision Air Conditioning
TC = Total Cooling
SC = Sensible Cooling
THR = Total Heat Rejection
(1) All data quoted is gross
(2) Interpolate for water temperatures between those quoted, do not extrapolate
(3) Water flow rate (l/s) = THR/(4.19*ΔT) at 100% Water; for glycol use refer to Ethylene Glycol Correction Factors section
Technical Data Downflow Units WX Type
Performance Data
Indoor Air Temperature
+18°C to +28°C
Indoor RH%
+40% to +55%
Condenser Minimum Entering Temperature °C
+25°C
Condenser Maximum Leaving Water Temperature °C
+45°C
Operating Limits
97
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
nic
al
W
X - T
yp
e
DF
Cooling Capacity (1)
Condenser Entering/Leaving Temperature - Based on 5°C ΔT
Air On
25°C/30°C
30°C/35°C
35°C/40°C
40°C/45°C
(DB°C/%RH) TC (kW) SC (kW)
THR
(kW)
TC (kW) SC (kW)
THR
(kW)
TC (kW) SC (kW)
THR
(kW)
TC (kW) SC (kW)
THR
(kW)
DF31WX-EZRE
22/50
28.4
28.2
38.3
28.4
28.2
38.3
28.0
27.9
38.1
26.6
26.6
37.5
24/45
29.7
29.7
39.7
29.7
29.7
39.7
29.3
29.3
39.5
27.9
27.9
39.0
26/40
31.2
31.2
41.3
31.2
31.2
41.3
30.8
30.8
41.1
29.5
28.9
40.7
DF35WX-EZRE
22/50
32.9
32.5
44.3
32.9
32.5
44.3
32.4
32.1
44.1
30.8
30.6
43.4
24/45
34.5
34.5
46.0
34.5
34.5
46.0
34.0
34.0
45.7
32.4
32.4
45.1
26/40
36.3
36.3
47.9
36.3
36.3
47.9
35.8
35.6
47.7
34.5
33.1
47.4
DF40WX-EZRE
22/50
36.7
36.6
49.3
36.7
36.6
49.3
36.1
36.1
49.0
34.3
34.3
48.3
24/45
38.5
38.5
51.2
38.5
38.5
51.2
37.9
37.9
50.9
36.1
36.1
50.3
26/40
40.4
40.4
53.3
40.4
40.4
53.3
39.9
39.8
53.1
38.5
37.1
52.8
DF45WX-EZRE
22/50
41.4
39.2
55.6
41.4
39.2
55.6
40.8
38.8
55.3
38.8
37.3
54.5
24/45
43.2
42.9
57.4
43.2
42.9
57.4
42.5
42.4
57.1
40.5
40.5
56.4
26/40
45.1
45.1
59.4
45.1
45.1
59.4
44.4
44.4
59.2
42.5
42.5
58.5
DF50WX2-EZRE
22/50
48.2
45.1
65.7
48.2
45.1
65.7
47.4
44.5
65.3
45.0
42.9
64.4
24/45
50.2
49.3
67.8
50.2
49.3
67.8
49.4
48.6
67.4
47.0
46.7
66.4
26/40
52.3
52.3
70.0
52.3
52.3
70.0
51.4
51.4
69.6
49.0
49.0
68.6
DF55WX2-EZRE
22/50
54.5
48.8
74.2
54.5
48.8
74.2
53.5
48.2
73.7
50.8
46.5
72.6
24/45
56.6
53.7
76.5
56.6
53.7
76.5
55.6
53.0
76.0
52.8
51.1
74.8
26/40
58.7
58.7
78.7
58.7
58.7
78.7
57.6
57.6
78.1
54.8
54.8
77.0
DF60WX2-EZRE
22/50
61.5
54.3
84.0
61.5
54.3
84.0
60.3
53.6
83.5
57.2
51.7
82.3
24/45
63.8
59.6
86.5
63.8
59.6
86.5
62.6
58.8
85.9
59.4
56.8
84.7
26/40
66.1
65.2
88.9
66.1
65.2
88.9
64.8
64.3
88.3
61.6
61.6
87.1
