EasiCool™
Precision Air Conditioning
DF35WX-EZRE-0
DF40WX-EZRE-0
DF45WX-EZRE-0
Capacity
Nom Cooling (Gross)
(1)
kW
34.5
38.5
43.2
Total Heat of Rejection
(1)
kW
46.0
51.2
57.4
Capacity Steps
1
1
1
Fan Power Input (Fan Gain)
(2)
kW
4.60
6.30
6.30
Dimensions - W x D x H
mm
1835 x 750 x 1940
1835 x 750 x 1940
1835 x 750 x 1940
Weight - Machine / Operating
(3)
kg
537 / 543
565 / 571
640 / 650
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
6.1
6.1
9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward CurvedAC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1
1
1
Motor Shaft Power
(4)
kW
4.00
5.50
5.50
Speed @ 25Pa / Maximum ESP
rpm
980 /1078
1094 / 1186
1094 / 1186
Maximum ESP
Pa
165
175
175
Nominal Airflow
m³/s
3.30
3.70
3.70
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
3.30
3.30
6.70
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total)
(5)
kg
6.0
6.0
8.7
Connections
Water Inlet / Outlet
mm
35
35
42
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
3
3
3
OPTIONAL EXTRAS
Electric Heating (Total)
kW
20.0
20.0
20.0
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
10.8
10.8
10.8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1
N/A
N/A
Motor Shaft Power
(4)
kW
5.50
N/A
N/A
Speed @ Maximum ESP
rpm
1196
N/A
N/A
Maximum ESP
Pa
322
N/A
N/A
Fan Power Input (Fan Gain)
(2)
kW
6.30
N/A
N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1895 / 2165
2135 / 2165
2135 / 2165
Maximum ESP
Pa
285
70
70
Fan Power Input (Fan Gain)
(2)
rpm
5.26
5.26
5.26
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
30.0
31.5
31.5
Water Flow (Nominal)
l/s
0.67
0.70
0.70
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
1 1/4
1 1/4
1 1/2
