EasiCool™
Precision Air Conditioning
62
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
DF
Technical Data Downflow Units X Type
Mechanical Data
DF6X-EZRE-0
DF8X-EZRE-0
DF10X-EZRE-0
Standard Condenser Match
1 x CR12
1 x CR16
1 x CR16
Capacity
Nom Cooling (Gross)
(1)
kW
6.5
8.4
10.8
Capacity Steps
1
1
1
Fan Power Input (Fan Gain)
(2)
kW
0.21
0.47
0.73
Dimensions - W x D x H
mm
670 x 670 x 1940
670 x 670 x 1940
670 x 670 x 1940
Weight - Machine
(3)
kg
194
195
199
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Evaporator Fan Motor - EC Motor
Centrifugal Forward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Maximum ESP
Pa
523
442
191
Nominal Airflow
m³/s
0.55
0.75
0.95
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
0.70
0.70
1.20
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
(5)
Inert Gas
Connections
Liquid (Sweat)
in
3/8
3/8
3/8
Discharge (Sweat)
in
1/2
1/2
1/2
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 50mm
Quantity
1
1
1
OPTIONAL EXTRAS
Larger Condenser Match
CR16
CR22
CR22
Nom Cooling (Gross)
(1)
kW
6.6
8.4
11.0
Hot Gas Reheat
Nom Heating (Gross)
(6)
kW
4.2
4.8
5.3
Electric Heating (Total)
kW
7.5
7.5
7.5
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1335 / 2215
1705 / 2215
2145 / 2215
Maximum ESP
Pa
475
295
50
Fan Power Input (Fan Gain)
(2)
kW
0.56
0.56
0.56
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
6.5
7.5
8.4
Water Flow (Nominal)
l/s
0.14
0.17
0.19
LPHW Connection Sizes
mm
22
22
22
DF6X - DF10X
