Page 92: Mechanical data
EasiCool™
Precision Air Conditioning
92
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
V
V50X2-EZRE-0
V55X2-EZRE-0
V60X2-EZRE-0
Standard Condenser Match
1 x CR80
1 x CR80
1 x CR80
Capacity
Nom Cooling (Gross)
(1)
kW
50.3
56.0
62.2
Capacity Steps
2
2
2
Fan Power Input (Fan Gain)
(2)
kW
7.00
7.00
7.00
Dimensions - W x D x H
mm
2170 x 750 x 1940
2170 x 750 x 1940
2170 x 750 x 1940
Weight - Machine
(3)
kg
619
636
640
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1
2/1
2/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
2
2
2
Motor Shaft Power
(4)
kW
3.0
3.0
3.0
Speed @ 25Pa / Maximum ESP
rpm
1243 / 1447
1243 / 1447
1278 / 1324
Maximum ESP
Pa
255
255
35
Nominal Airflow
m³/s
4.20
4.20
4.60
Compressor - Scroll
Tandem
Tandem
Tandem
Quantity
2
2
2
Oil Charge Volume (Total)
l
6.60
6.60
6.60
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
(5)
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
5/8
5/8
5/8
Discharge (Sweat)
in
1 3/8
1 3/8
1 3/8
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
5
5
5
OPTIONAL EXTRAS
Larger Condenser Match
CR105
CR105
CR105
Nom Cooling (Gross)
(1)
kW
50.9
57.1
63.7
Hot Gas Reheat
Nom Heating (Gross)
(6)
kW
25.7
25.7
26.7
Electric Heating (Total)
kW
30.0
30.0
30.0
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
10.8
10.8
10.8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
2
2
2
Motor Shaft Power
(4)
kW
4.0
4.0
4.0
Speed @ Maximum ESP
rpm
1495
1495
1499
Maximum ESP
Pa
305
305
230
Fan Power Input (Fan Gain)
(2)
kW
9.20
9.20
9.20
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1370 / 1510
1370 / 1510
1510 / 1510
Maximum ESP
Pa
165
165
25
Fan Power Input (Fan Gain)
(2)
kW
4.18
4.18
4.18
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
37.7
37.7
39.2
Water Flow (Nominal)
l/s
0.84
0.84
0.87
LPHW Connection Sizes
mm
22
22
22
V50X2 - V60X2
Technical Data Upflow Units X Type
Mechanical Data
