Page 91: Electrical data
EasiCool™
Precision Air Conditioning
91
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
nic
al
X-T
yp
e
V
V35X - V45X2
V35X-EZRE-0
V35X2-EZRE-0
V40X-EZRE-0
V40X2-EZRE-0
V45X2-EZRE-0
Standard Condenser Match
1 x CR50
1 x CR50
1 x CR65
1 x CR65
1 x CR65
Max Mains Incoming Cable Size
mm²
35
35
35
35
35
Mains Supply
V
400V / 3PH + N / 50HZ
Control Circuit
VAC
24
24
24
24
24
Unit Data Full Function - X
(1)
Nominal Run Amps
A
76.6
76.0
80.6
83.3
87.2
Maximum Start Amps
A
220.2
140.6
217.9
172.6
169.9
Recommended Mains Fuse Size
A
100
100
100
100
100
Unit Data Cooling Only - X
Nominal Run Amps
(2)
A
33.3
32.7
37.3
40.0
43.9
Maximum Start Amps
A
176.9
97.3
174.6
129.3
126.6
Recommended Mains Fuse Size
A
40
40
50
50
50
Evaporator Fan - AC Motor Per Fan
Centrifugal Forward Curved Belt & Pulley AC - Designed to 25Pa ESP
Quantity
1
1
1
1
1
Maximum Electrical Input Power
(3)
kW
4.6
4.6
6.3
6.3
6.3
Full Load Amps
A
8.12
8.12
10.9
10.9
10.9
Locked Rotor Amps
A
60.9
60.9
69.8
69.8
69.8
Compressor - Per Compressor
Quantity x Motor Size
kW
1 x 10.85
2 x 5.6
1 x 12.15
2 x 6.4
2 x 6.8
Nominal Run Amps
A
19.4
9.4
20.7
11.7
12.3
Locked Rotor Amps
A
163
74
158
101
95
Type of Start
Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Quantity
2
2
2
2
3
Maximum Electrical Input Power
kW
0.6
0.6
0.6
0.6
0.6
Full Load Amps
A
2.62
2.62
2.62
2.62
2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
3
3
Number of Elements
12
12
12
12
12
Rating
kW
30
30
30
30
30
Current per Phase
A
43.30
43.30
43.30
43.30
43.30
Humidifier
Capacity
kg/hr
15
15
15
15
15
Rating
kW
11.25
11.25
11.25
11.25
11.25
Full Load Amps
A
16.24
16.24
16.24
16.24
16.24
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Centrifugal Forward Curved Belt & Pulley AC - Designed to 25Pa ESP
Quantity
1
1
Maximum Electrical Input Power
(3)
kW
5.5
5.5
N/A
N/A
N/A
Full Load Amps
A
10.9
10.9
N/A
N/A
N/A
Locked Rotor Amps
A
69.8
69.8
N/A
N/A
N/A
Standard Size Motor - EC Motor - Per Fan
Centrifugal Backward Curved DD EC - Designed to 25Pa ESP
Quantity
2
2
2
2
2
Quantity x Motor Size
(3)
kW
2.55
2.55
2.55
2.55
2.55
Full Load Amps
A
3.9
3.9
3.9
3.9
3.9
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Quantity
2
2
2
2
2
Maximum Electrical Input Power
(3)
kW
0.73
0.73
0.73
0.73
0.73
Full Load Amps
A
3.3
3.3
3.3
3.3
3.3
Technical Data Upflow Units X Type
Electrical Data
Mechanical
(1)
Entering air 24°C/45% RH ambient 35°C.
(2)
Fan Gain / Fan power input based upon fan operating with design airflow at 25Pa ESP, these values may change with different ESP.
(3)
With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4)
Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5)
For refrigerant charges, refer to
Unit Refrigerant Charge (kg/Circuit)
.
(6)
Based on air temperature of 15.5°C leaving the evaporator coil.
(7)
Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to
Low Pressure Hot Water
.
Electrical
(1)
Values given for full function units (incl. electric heating, humidification and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2)
Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3)
Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
