EasiCool™
Precision Air Conditioning
V28WX-EZRE-0
V28WX2-EZRE-0
V31WX-EZRE-0
V31WX2-EZRE-0
Capacity
Nom Cooling (Gross)
(1)
kW
26.5
26.4
30.1
29.8
Total Heat of Rejection
(1)
kW
35.4
34.7
40.2
39.4
Capacity Steps
1
2
1
2
Fan Power Input (Fan Gain)
(2)
kW
3.50
3.50
4.60
4.60
Dimensions - W x D x H
mm
1460 x 750 x 1940
1460 x 750 x 1940
1460 x 750 x 1940
1460 x 750 x 1940
Weight - Machine / Operating
(3)
kg
468 / 474
477 / 483
468 / 474
500 / 506
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
2/1
1/1
2/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
6.1
6.1
6.1
6.1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1
1
1
1
Motor Shaft Power
(4)
kW
3.00
3.00
4
4
Speed @ 25Pa / Maximum ESP
rpm
1420 / 1552
1420 / 1552
1600 / 1612
1600 / 1612
Maximum ESP
Pa
160
160
35.00
35.00
Nominal Airflow
m³/s
2.40
2.40
2.8
2.8
Compressor - Scroll
Single
Tandem
Single
Tandem
Quantity
1
2
1
2
Oil Charge Volume (Total)
l
3.30
2.48
3.3
3.32
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total)
(5)
kg
5.3
5.2
5.3
5.2
Connections
Water Inlet / Outlet
mm
35
35
35
35
Condensate Drain Hose
mm
19
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
3
3
3
3
OPTIONAL EXTRAS
Electric Heating (Total)
kW
22.5
22.5
22.5
22.5
Humidifier
Capacity
kg/hr
1.6 - 8.0
1.6 - 8.0
1.6 - 8.0
1.6 - 8.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
10.8
10.8
10.8
10.8
Flow
l/m
5
5
5
5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1
1
N/A
N/A
Motor Shaft Power
(4)
kW
4
4
N/A
N/A
Speed @ Maximum ESP
rpm
1910
1910
N/A
N/A
Maximum ESP
Pa
470
470
N/A
N/A
Fan Power Input (Fan Gain)
(2)
kW
4.60
4.60
N/A
N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
kW
2
2
2
2
Motor Shaft Power
(4)
N/A
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1700 / 2165
1700 / 2165
1935 / 2165
1935 / 2165
Maximum ESP
Pa
440.00
440.00
225
225
Fan Power Input (Fan Gain)
(2)
kW
2.02
2.02
3.02
3.02
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
21.70
21.70
23.2
23.2
Water Flow (Nominal)
l/s
0.48
0.48
0.52
0.52
LPHW Connection Sizes
mm
22
22
22
22
Threaded Connection
Brass Male Taper
in
1 1/4
1 1/4
1 1/4
1 1/4
V28WX - V31WX2
Technical Data Upflow Units WX Type
Mechanical Data
124
EasiCool Technical Manual 7525389 V1.1.0_02_2013
