Page 90: Mechanical data
EasiCool™
Precision Air Conditioning
90
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
V
V35X-EZRE-0
V35X2-EZRE-0
V40X-EZRE-0
V40X2-EZRE-0
V45X2-EZRE-0
Standard Condenser Match
1 x CR50
1 x CR50
1 x CR65
1 x CR65
1 x CR80
Capacity
Nom Cooling (Gross)
(1)
kW
34.2
33.2
38.7
39.3
43.0
Capacity Steps
1
2
1
2
2
Fan Power Input (Fan Gain)
(2)
kW
4.60
4.60
6.30
6.30
6.30
Dimensions - W x D x H
mm
1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940
Weight - Machine
(3)
kg
474
516
497
525
531
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
2/1
1/1
2/1
2/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1
1
1
1
1
Motor Shaft Power
(4)
kW
4.00
4.00
4.00
4.00
5.50
Speed @ 25Pa / Maximum ESP
rpm
1440 / 1468
1440 / 1468
1620 / 1622
1620 / 1622
1620 / 1622
Maximum ESP
Pa
35
35
25
25
25
Nominal Airflow
m³/s
3.30
3.30
3.70
3.70
3.70
Compressor - Scroll
Single
Tandem
Single
Tandem
Tandem
Quantity
1
2
1
2
2
Oil Charge Volume (Total)
l
3.30
3.32
3.30
3.78
3.44
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
(5)
Inert Gas
Connections
Liquid (Sweat)
in
1/2
1/2
5/8
5/8
5/8
Discharge (Sweat)
in
7/8
7/8
1 1/8
7/8
7/8
Condensate Drain Hose
mm
19
19
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
4
4
4
4
4
OPTIONAL EXTRAS
Larger Condenser Match
CR65
CR65
CR80
CR80
CR105
Nom Cooling (Gross)
(1)
kW
35.0
34.2
39.0
39.7
43.0
Hot Gas Reheat
Nom Heating (Gross)
(6)
kW
19.4
19.4
20.3
20.3
20.3
Electric Heating (Total)
kW
30.0
30.0
30.0
30.0
30.0
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
10.8
10.8
10.8
10.8
10.8
Flow
l/m
5
5
5
5
5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1
1
N/A
N/A
N/A
Motor Shaft Power
(4)
kW
5.5
5.5
N/A
N/A
N/A
Speed @ Maximum ESP
rpm
1695
1695
N/A
N/A
N/A
Maximum ESP
Pa
240
240
N/A
N/A
N/A
Fan Power Input (Fan Gain)
(2)
kW
6.30
6.30
N/A
N/A
N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1935 / 2165
1935 / 2165
2165 / 2165
2165 / 2165
2165 / 2165
Maximum ESP
Pa
260
260
25
25
25
Fan Power Input (Fan Gain)
(2)
kW
3.08
3.08
4.24
4.24
4.24
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
29.9
29.9
31.5
31.5
31.5
Water Flow (Nominal)
l/s
0.67
0.67
0.70
0.70
0.70
LPHW Connection Sizes
mm
22
22
22
22
22
V35X - V45X2
Technical Data Upflow Units X Type
Mechanical Data
