Page 100: Df6wx - df10wx
EasiCool™
Precision Air Conditioning
Technical Data Downflow Units WX Type
Mechanical Data
100
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
ni
ca
l
DF
W
X - T
yp
e
DF6WX-EZRE-0
DF8WX-EZRE-0
DF10WX-EZRE-0
Capacity
Nom Cooling (Gross)
(1)
kW
6.6
8.4
11.0
Total Heat of Rejection
(1)
kW
8.5
10.9
14.3
Capacity Steps
1
1
1
Fan Power Input (Fan Gain)
(2)
kW
0.21
0.47
0.73
Dimensions - W x D x H
mm
670 x 670 x 1940
670 x 670 x 1940
670 x 670 x 1940
Weight - Machine / Operating
(3)
kg
210 / 212
215 / 216
218 / 219
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
1.1
1.4
1.4
Evaporator Fan Motor - EC Motor
Centrifugal Forward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Maximum ESP
Pa
523
442
191
Nominal Airflow
m³/s
0.55
0.75
0.95
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
0.70
0.70
1.20
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total)
(5)
kg
1.4
1.6
1.6
Connections
Water Inlet / Outlet
mm
22
22
22
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 50mm
Quantity
1
1
1
OPTIONAL EXTRAS
Electric Heating (Total)
kW
7.5
7.5
7.5
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved DD EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1335 / 2215
1705 / 2215
2145 / 2215
Maximum ESP
Pa
475
295
50
Fan Power Input (Fan Gain)
(2)
kW
0.23
0.43
0.77
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
6.5
7.5
8.4
Water Flow (Nominal)
l/s
0.14
0.17
0.19
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
3/4
3/4
3/4
DF6WX - DF10WX
