EasiCool™
Precision Air Conditioning
Technical Data Downflow Units WX Type
Mechanical Data
102
EasiCool Technical Manual 7525389 V1.1.0_02_2013
Te
ch
ni
ca
l
DF
W
X - T
yp
e
DF13WX-EZRE-0
DF15WX-EZRE-0
DF17WX-EZRE-0
Capacity
Nom Cooling (Gross)
(1)
kW
14.1
16.0
18.3
Total Heat of Rejection
(1)
kW
18.4
20.9
24.1
Capacity Steps
1
1
1
Fan Power Input (Fan Gain)
(2)
kW
0.52
0.67
1.01
Dimensions - W x D x H
mm
990 x 670 x 1940
990 x 670 x 1940
990 x 670 x 1940
Weight - Machine / Operating
(3)
kg
240 / 241
271 / 273
275 / 277
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
1.4
2.0
2.5
Evaporator Fan Motor - EC Motor
Centrifugal Forward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Maximum ESP
Pa
307
405
190
Nominal Airflow
m³/s
1.00
1.20
1.40
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
1.20
1.66
1.89
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total)
(5)
kg
2.1
2.6
2.6
Connections
Water Inlet / Outlet
mm
22
22
28
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 50mm
Quantity
2
2
2
OPTIONAL EXTRAS
Electric Heating (Total)
kW
7.5
7.5
7.5
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1105 / 1560
1310 / 1560
1515 / 1560
Maximum ESP
Pa
310
195
45
Fan Power Input (Fan Gain)
(2)
kW
0.37
0.56
0.82
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross
(7)
kW
11.5
12.5
13.3
Water Flow (Nominal)
l/s
0.26
0.28
0.30
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
3/4
3/4
1
DF13WX - DF17WX
