65
Er 9 - ADC Reference 1. Perform the CAL2 procedure as described in the
Number Error Calibration section (page 52).
Er10 - ADC Reference 1. Perform the CAL2 procedure as described in the
Voltage Error Calibration section (page 52).
Er11 - Cold Junction 1. Perform the CAL3 procedure as described in the
Compensation Error Calibration section (page 53).
Er12 - CAL2 Voltage Error 1. Check that 50 mVDC is properly connected to the
instrument and is within the tolerance limits as
indicated in the CAL2 procedure of the Calibration
section (page 52).
2. Turn off the power to the instrument and open the
cover. Loosen the platen hold down screw and swing
the platen open. Inspect the Processor board
(Appendix A-1, page 67) to insure that the input
conditioning jumper JU4 is in the non-volt position.
3. Perform the CAL2 procedure as described in the
Calibration section (page 52).
Er13 - RTD CAL5 Input 1. Check that resistance device is of the correct value
Error and properly connected to the instrument and is
within the tolerance limits as indicated in the CAL5
procedure of the Calibration section (page 54).
2. Turn off the power to the instrument and open the
cover. Loosen the platen hold down screw and swing
the platen open. Inspect the Processor board
(Appendix A-1, page 67) to insure that the input
conditioning jumpers are in the correct position for the
RTD input for the Terminal Board being calibrated.
For TB 4, JU4 should be in the non-volt position and
JU6 in the RTD position. For TB 5, JU5 should be in
the non-volt position and JU7 in the RTD position.
3. Perform the CAL5 procedure as described in the
Calibration section (page 54).
Er14 - Cold Junction 1. Perform the CAL3 procedure as described in the
Compensation Error Calibration section (page 53).
Er15 - Ground Reference 1. Perform the CAL2 procedure as described in the
Tolerance Error Calibration section (page 52).
Er16 - Program/ASEt Mode 1. Record all Program and Tune mode parameters.
Checksum Error Perform CAL 1 procedure as described in the
Calibration section (page 52). Re-enter the
Program and ASEt mode parameters.
Er17 - Calibration 1. Perform the calibration procedures that are
Checksum Error needed for the input sensors that will be used (page
51).
Er18 - Profile Data 1. Record all Profile data that was entered. Perform the
Checksum Error CAL 8 procedure as described in the Calibation
section (page 54). Re-enter the Profile data as
needed.
