23 Profile End Control PEnd -1=Hold at least setpoint 0
0= Abort- all outputs off or
at 0% Event off
1=Transfer to profile 1
2=Transfer to profile 2
3=Transfer to profile 3
4=Transfer to profile 4
5=Transfer to profile 5
6=Transfer to profile 6
7=Transfer to profile 7
8=Transfer to profile 8
After selecting the Profile End Control parameter value, press the SCROLL key to advance
the display to Pn. Press the UP key with Pn or any parameter code displayed to exit the
Profile Entry Mode.
* Event outputs will remain in their current status during an error condition (i.e. Sensor break
SnSr) and upon entering the Profile Continue mode PCon but will turn off when entering other
non-control modes (i.e. Program Mode Prog).
** All values except Profile Loop Count PLCt are initialized to zero and all event outputs are
initialed to OFF, with the exception of hte first profile. Profle Loop count PLCt is set to 1.
The first profile has the number of segments initalized to zero, to turn the profile OFF, but the
profile has values stored in it for demonstration purposes. By setting the number of seg-
ments to two, the profile can be reviewed and/or executed.
PROFILE 1 VALUES FOR DEMONSTRATION PURPOSES
Code Value
rt .10 Ramp Time
SP 100 Setpoint
E1 on Event 1 on
E2 oFF Event 2 off
E3 oFF Event 3 off
St .10 Soak Time
E1 oFF Event 1 off
E2 on Event 2 on
E3 oFF Event 3 off
rt .10 Ramp Time
SP 0 Setpoint
E1 oFF Event 1 off
E2 oFF Event 2 off
E3 on Event 3 on
St .10 Soak Time
E1 oFF Event 1 off
E2 oFF Event 2 off
E3 oFF Event 3 off
PLct 1 Profile Loop Count
dhru 0 Deviation Hold after Ramp Up - None
dhrd 0 Deviation Hold after Ramp Down - None
PEnd 0 Profile End Control - Abort - oFF mode
DISPLAY AVAILABLE FACTORY YOUR
STEP DESCRIPTION CODES SETTINGS SETTING SETTING
