44
TABLE 4-1 PROFILE CONTINUE MODE
DISPLAY
STEP DESCIPTION CODE ACTION
1 Profile Pn Press the SCROLL key to see the number of
Number the last active profile.
2 Profile X If necessary, use the UP or DOWN key to
Number change the profile number to the desired value,
Value then press the SCROLL key.
3 Segment Sn Press the SCROLL key to see the number of
Number the last active segment.
4 Segment X If necessary, use the Up or Down key to change
Number the segment number to the desired value, then
Value press the SCROLL key. DO NOT SET THIS
VALUE TO 0 AND ATTEMPT TO RUN THE
PROFILE. AN ERROR 19 CODE WILL DIS
PLAY AND THE PROFILE WILL NOT RUN.
5 Ramp Time rtr Press the SCROLL key to see the Ramp Time
Remaining Remaining value.
6 Ramp Time X If necessary, use the UP or DOWN key to
Remaining adjust the Ramp Time Remainig value, then
Value press the SCROLL key. If the time remaining is
set to 0 when the SCROLL key is pressed the
Soak Time Remaining code will be displayed. If
the time remaining is greater than 0 then the
display will advance to the events, if
programmed. If no events are programmed, the
display will advance to Profile Loop Count.
7 Soak Time Str Press the SCROLL key to see the Soak Time
Remaining Remaining value of the last active profile.
8 Soak Time X If necessary, use the UP or DOWN key to
Remaining adjust the Soak Time Remaining value, then
Value press the SCROLL key.
9 Event(s) E1-E6 If any event outputs have been selected in the
Program mode then each event number
selected will be displayed in sequence. Press
the SCROLL key to see the status of the
event(s).
10 Event(s) Status on/oFF If necessary, use the UP key to turn on an event
that is off or the DOWN key to turn off an event
that is on. Press the SCROLL key to see the
next event number. After the last event status is
selected pressing the SCROLL key will
advance the display to PLCt. The SCROLL key
must be depressed whenever a change is made
to the events. Depressing the RUN/HOLD key
without first depressing the SCROLL key would
result with the profile running without the status
of the events being changed.
11 Profile Loop PLCt Press the SCROLL key to see the Profile Loop
Count Remaining Count Remaining for the last active profile.
12 Profile Loop X If necessary,use the UP or Down key to adjust
Remaining the Profile Loop Count Remaining value.
